Rail:
Medium Carbon Steel with nickel and chrome plating.
Wooden Handle:
Easy and comfortable to hold.
Screws:
Gardened screws for strong tightening force
Clamping Force:
200 KGF
Anti-Slip System:
The Anti-Slip System is really handy in work.
1. Prevents the lower jaw sliding or un-clamping.
2. Let the lower jaw clip and stop anywhere at the rail.
Parallel Jaw:
Material: Polyamide
The large clamping area and parallel jaws allow the work easier and prevent damaging your work piece.
Pad:
Material: Steel
Arm:
Ductile cast iron
Stopper:
1. Material: Polyamide
2. Prevents the sliding arm moving off.
3. Can be taken off by hand for quickly changing the siding arm direction to use for spreading.
4. Also can be a hold with the fixed arm to put on the table for horizontal clamping.
Item NO. | Span x Depth
mm | Spreading
mm | Rail
mm | Weight
kg | Pressure
kg | Pack
pcs |
PJ16 | 160 X 80 | 172-270 | 20.0 X 5.0 | 0.6 | 200 | 10 |
PJ30 | 300 X 80 | 172-415 | 0.7 |
PJ60 | 600 X 80 | 172-720 | 0.9 |
